Attenuation ratio
100:1
-
Bandwidth
DC to 100MHz
-
Rise time
3.5nS
-
Input impedance
300MΩ
-
Compensation range
10 to 35 pF
-
Input voltage
20KV DC/Peak AC ＜ 30s
-
Temperature and humidity
0℃ to 50 ℃；85% RH
-
Overall length
2m
-
-
-
Attenuation ratio
1000:1
-
Bandwidth
DC to 50MHz
-
Rise time
3.5nS
-
Input impedance
900MΩ
-
Compensation range
10 to 35 pF
-
Input voltage
20KV DC/Peak AC ＜ 30s
-
Temperature and humidity
0℃ to 40 ℃；80% RH
-
Overall length
2m
-
-
-
Attenuation ratio
100:1
-
Bandwidth
DC to 100MHz
-
Rise time
3.5nS
-
Input impedance
300MΩ
-
Compensation range
10 to 35 pF
-
Input voltage
30KV DC/Peak AC ＜ 30s
-
Temperature and humidity
0℃ to 50 ℃；85% RH
-
Overall length
2m
-
-
-
Attenuation ratio
100:1
-
Bandwidth
DC to 50MHz
-
Rise time
7nS
-
Input impedance
900MΩ
-
Compensation range
10 to 35 pF
-
Input voltage
40KV DC/Peak AC ＜ 30s
-
Temperature and humidity
0℃ to 50 ℃；85%
-
Overall length
2m
-
-
-
Attenuation ratio
100:1
-
Bandwidth
DC to 50MHz
-
Rise time
7nS
-
Input impedance
900MΩ
-
Compensation range
10 to 35 pF
-
Input voltage
50KV DC/Peak AC ＜ 30s
-
Temperature and humidity
0℃ to 50 ℃；85% RH
-
Overall length
2m
-
-
-
Attenuation ratio
100:1
-
Bandwidth
DC to 100MHz
-
Rise time
3.5nS
-
Input impedance
100MΩ
-
Input capacitance
5.5 pF
-
Compensation range
10 to 30 pF
-
Input voltage
2000V DC/Peak AC
-
Temperature and humidity
0℃ to 50 ℃；85% RH
-
Overall length
1.35m
-
