Bandwidth
DC-30MHz
-
Current
DC/AC RMS 50A
-
Rise time
≤11.7ns
-
Range sensitivity
0.1V/A 1V/A
-
Typical DC Accuracy
士1%+1mA@1V/A 士1%+10mA@0.1V/A
-
Maximum operating voltage
600V CATII 300V CATIII
-
Zero adjustment mode
Automatic
-
Power supply modenction
12V/2A power supply
-
Jaw diameter
Φ5mm
-
Interface Type
BNC
-
Weight
255g
-
Overall dimension
Current clamp handle size (length * width * height):176mm x 39.5mm x 18mm// Control box size (length * width * height):91.5mm x 40mm x 26.5mm
-
Delay time
Probe host 14ns //BNC 5ns (line length 1 m)
-
Cable length
Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m
-
-
-
Bandwidth
DC-120MHz
-
Current
DC/AC RMS 30A
-
Rise time
≤2.92ns
-
Range sensitivity
0.1V/A 1V/A
-
Typical DC Accuracy
士1%+1mA@1V/A 士1%+10mA@0.1V/A
-
Maximum operating voltage
600V CATII 300V CATIII
-
Zero adjustment mode
Automatic
-
Power supply modenction
12V/2A power supply
-
Jaw diameter
Φ5mm
-
Interface Type
BNC
-
Weight
255g
-
Overall dimension
Current clamp handle size:176mm x 39.5mm x 18mm// Control box size:91.5mm x 40mm x 26.5mm
-
Delay time
Probe host 14ns //BNC 5ns (line length 1 m)
-
Cable length
Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m
-
-
-
Bandwidth
DC-50MHz
-
Current
DC/AC RMS 50A
-
Rise time
≤7ns
-
Range sensitivity
0.1V/A 1V/A
-
Typical DC Accuracy
士1%+1mA@1V/A 士1%+10mA@0.1V/A
-
Maximum operating voltage
600V CATII 300V CATIII
-
Zero adjustment mode
Automatic
-
Power supply modenction
12V/2A power supply
-
Jaw diameter
Φ5mm
-
Interface Type
BNC
-
Weight
255g
-
Overall dimension
Current clamp handle size (length * width * height):176mm x 39.5mm x 18mm// Control box size (length * width * height):91.5mm x 40mm x 26.5mm
-
Delay time
Probe host 14ns //BNC 5ns (line length 1 m)
-
Cable length
Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m
-
-
-
Bandwidth
DC-50MHz
-
Current
DC/AC RMS 30A
-
Rise time
≤7ns
-
Range sensitivity
0.1V/A 1V/A
-
Typical DC Accuracy
士1%+5mA@1V/A 士1%+20mA@0.1V/A
-
Maximum operating voltage
600V CATII 300V CATIII
-
Zero adjustment mode
Automatic
-
Power supply modenction
12V/2A power supply
-
Jaw diameter
Φ5mm
-
Interface Type
BNC
-
Weight
255g
-
Overall dimension
Current clamp handle size :176mm x 39.5mm x 18mm// Control box size :91.5mm x 40mm x 26.5mm
-
Delay time
Probe host 14ns //BNC 5ns (line length 1 m)
-
Cable length
Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m
-
-
-
Bandwidth
DC-30MHz
-
Current
DC/AC RMS 30A
-
Rise time
≤11.7ns
-
Range sensitivity
0.1V/A 1V/A
-
Typical DC Accuracy
士1%+5mA@1V/A 士1%+20mA@0.1V/A
-
Maximum operating voltage
600V CATII 300V CATIII
-
Zero adjustment mode
Automatic
-
Power supply modenction
12V/2A power supply
-
Jaw diameter
Φ5mm
-
Interface Type
BNC
-
Weight
255g
-
Overall dimension
Current clamp handle size (length * width * height):176mm x 39.5mm x 18mm// Control box size (length * width * height):91.5mm x 40mm x 26.5mm
-
Delay time
Probe host 14ns //BNC 5ns (line length 1 m)
-
Cable length
Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m
-
-
-
Bandwidth
DC-60MHz
-
Current
DC/AC RMS 30A
-
Rise time
≤5.84ns
-
Range sensitivity
0.1V/A 1V/A
-
Typical DC Accuracy
士1%+1mA@1V/A 士1%+10mA@0.1V/A
-
Maximum operating voltage
600V CATII 300V CATIII
-
Zero adjustment mode
Automatic
-
Power supply modenction
12V/2A power supply
-
Jaw diameter
Φ5mm
-
Interface Type
BNC
-
Weight
255g
-
Overall dimension
Current clamp handle size (length * width * height):176mm x 39.5mm x 18mm// Control box size (length * width * height):91.5mm x 40mm x 26.5mm
-
Delay time
Probe host 14ns //BNC 5ns (line length 1 m)
-
Cable length
Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m
-
-
-
Bandwidth
DC-100MHz
-
Current
DC/AC RMS 30A
-
Rise time
≤3.5ns
-
Range sensitivity
0.1V/A 1V/A
-
Typical DC Accuracy
士1%+5mA@1V/A 士1%+20mA@0.1V/A
-
Maximum operating voltage
600V CATII 300V CATIII
-
Zero adjustment mode
Automatic
-
Power supply modenction
12V/2A power supply
-
Jaw diameter
Φ5mm
-
Interface Type
BNC
-
Weight
255g
-
Overall dimension
Current clamp handle size:176mm x 39.5mm x 18mm// Control box size:91.5mm x 40mm x 26.5mm
-
Delay time
Probe host 14ns //BNC 5ns (line length 1 m)
-
Cable length
Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m
-
-
-
Bandwidth
10Hz-5MHz
-
Current
AC 400A RMS
-
Pulse Current
AC 20000A peak
-
Accuracy
±1%
-
Rise time
≤200ns
-
Range sensitivity
1mV/A
-
Input impedance
1MΩ
-
Opening diameter
50mm
-
Cable length
100mm
-
Overall dimension
134.6x108x32mm
-
Weight
720g
-
Temperature and humidity
-20~80°C、＜80% RH
-
-
-
Bandwidth
10Hz-5MHz
-
Current
AC 100A RMS
-
Pulse Current
AC 10000A peak
-
Accuracy
±1%
-
Rise time
≤100ns
-
Range sensitivity
10mV/A
-
Input impedance
1MΩ
-
Opening diameter
14mm
-
Cable length
100mm
-
Overall dimension
83.5x60x20mm
-
Weight
380g
-
Temperature and humidity
-20~80°C、less than 80% RH
-
-
-
Bandwidth
10Hz-10MHz
-
Current
AC 50A RMS
-
Pulse Current
AC 4000A peak
-
Accuracy
±1%
-
Rise time
≤50ns
-
Range sensitivity
50mV/A
-
Input impedance
1MΩ
-
Opening diameter
14mm
-
Cable length
100mm
-
Overall dimension
83.5x60x20mm
-
Weight
380g
-
Temperature and humidity
-20~80°C、less than 80% RH
-
