Bandwidth

200MHz

Rise time

≤1.75ns

Accuracy

±2%

Attenuation ratio

50X;500X

Voltage range

±1500V DC+Peak AC

Common mode voltage

±1500V DC+ Peak AC

Maximum input voltage to ground

600V CAT III 1000V CAT II Vrms

Delay time

14ns

Input impedance

Single-ended to ground 5MΩ ± 1%；
Two input terminals 10MΩ ± 1%

Input capacitance

Single-ended to ground ＜4pF ；Two input terminals ＜2pF

CMRR

DC > 80dB ;100KHz > 60dB; 1MHZ > 50dB; 3.2MHz > 30dB; 50MHz > 26dB

Noise level

50X ＜ 50mVrms ; 500X ＜ 300mVrms

Overload indication voltage threshold

50X ≥ 150V; 500X ≥ 1500V

Bandwidth Limit (5MHZ)

≥-3dB @ 5MHZ

Overload indicator lamp

Red Light

Overload alarm sound

support; optionally off

Bias adjustable function

Support

Terminal load requirements

≥100kΩ

Power

USB 5V/1A Adapter

Attenuation ratio

100:1

Bandwidth

DC to 100MHz

Rise time

3.5nS

Input impedance

300MΩ

Compensation range

10 to 35 pF

Input voltage

20KV DC/Peak AC ＜ 30s

Temperature and humidity

0℃ to 50 ℃；85% RH

Overall length

2m

Attenuation ratio

1000:1

Bandwidth

DC to 50MHz

Rise time

3.5nS

Input impedance

900MΩ

Compensation range

10 to 35 pF

Input voltage

20KV DC/Peak AC ＜ 30s

Temperature and humidity

0℃ to 40 ℃；80% RH

Overall length

2m

Attenuation ratio

100:1

Bandwidth

DC to 100MHz

Rise time

3.5nS

Input impedance

300MΩ

Compensation range

10 to 35 pF

Input voltage

30KV DC/Peak AC ＜ 30s

Temperature and humidity

0℃ to 50 ℃；85% RH

Overall length

2m

Attenuation ratio

100:1

Bandwidth

DC to 50MHz

Rise time

7nS

Input impedance

900MΩ

Compensation range

10 to 35 pF

Input voltage

40KV DC/Peak AC ＜ 30s

Temperature and humidity

0℃ to 50 ℃；85%

Overall length

2m

Attenuation ratio

100:1

Bandwidth

DC to 50MHz

Rise time

7nS

Input impedance

900MΩ

Compensation range

10 to 35 pF

Input voltage

50KV DC/Peak AC ＜ 30s

Temperature and humidity

0℃ to 50 ℃；85% RH

Overall length

2m

Bandwidth

10Hz-5MHz

Current

AC 400A RMS

Pulse Current

AC 20000A peak

Accuracy

±1%

Rise time

≤200ns

Range sensitivity

1mV/A

Input impedance

1MΩ

Opening diameter

50mm

Cable length

100mm

Overall dimension

134.6x108x32mm

Weight

720g

Temperature and humidity

-20~80°C、＜80% RH

Bandwidth

10Hz-5MHz

Current

AC 100A RMS

Pulse Current

AC 10000A peak

Accuracy

±1%

Rise time

≤100ns

Range sensitivity

10mV/A

Input impedance

1MΩ

Opening diameter

14mm

Cable length

100mm

Overall dimension

83.5x60x20mm

Weight

380g

Temperature and humidity

-20~80°C、less than 80% RH

Bandwidth

10Hz-10MHz

Current

AC 50A RMS

Pulse Current

AC 4000A peak

Accuracy

±1%

Rise time

≤50ns

Range sensitivity

50mV/A

Input impedance

1MΩ

Opening diameter

14mm

Cable length

100mm

Overall dimension

83.5x60x20mm

Weight

380g

Temperature and humidity

-20~80°C、less than 80% RH

Bandwidth

10Hz-20MHz

Current

AC 20A RMS

Pulse Current

AC 2000A peak

Accuracy

±1%

Rise time

≤20ns

Range sensitivity

100mV/A

Input impedance

1MΩ

Opening diameter

14mm

Cable length

100mm

Overall dimension

83.5x60x20mm

Weight

380g

Temperature and humidity

-20~80°C、less than 80% RH
