Bandwidth

DC-300KHz

Current

DC/AC peak 200A

Rise time

≤1.2us

Range sensitivity

100mV/A、10mV/A

Typical DC Accuracy

3% ± 50mA

Maximum operating voltage

CATI600V、CATI 600V、CATII 300V

Typical battery type and life

9VNEDA 1604A,IEC 6LR6113 hours minimum (l each)

Zero adjustment mode

Manual

Low battery indication function

Battery voltage <6.5V, indicator red

Overload indication

Current exceeds range, buzzer sounds

Jaw diameter

Φ11mm

Bandwidth

DC-300KHz

Current

DC/AC peak 100A

Rise time

≤1.2us

Range sensitivity

100mV/A、10mV/A

Typical DC Accuracy

3% ± 50mA

Maximum operating voltage

CATI600V、CATI 600V、CATII 300V

Typical battery type and life

9VNEDA 1604A,IEC 6LR6113 hours minimum

Zero adjustment mode

Manual

Low battery indication function

Battery voltage <6.5V, indicator red

Overload indication

Current exceeds range, buzzer sounds

Jaw diameter

Φ11mm

Bandwidth

DC-500KHz

Current

DC/AC peak 100A

Rise time

≤700ns

Range sensitivity

100mV/A、10mV/A

Typical DC Accuracy

3% ± 50mA

phase shift

DC~65Hz:＜1.5°

Maximum operating voltage

CATI600V、CATI 600V、CATII 300V

Zero adjustment mode

Manual

Power supply modenction

5V/2A power supply

Overload indication

Current overrange, indicator light red

Jaw diameter

Φ13mm

Interface Type

BNC

Weight

283g

Overall dimension

100 mmx23mmx55 mm

Bandwidth

DC-1MHz

Current

DC/AC peak 100A

Rise time

≤350ns

Range sensitivity

100mV/A、10mV/A

Typical DC Accuracy

3% ± 50mA

phase shift

DC~65Hz:＜1.5°

Maximum operating voltage

CATI600V、CATI 600V、CATII 300V

Zero adjustment mode

Manual

Power supply modenction

5V/2A power supply

Overload indication

Current overrange, indicator light red

Jaw diameter

Φ13mm

Interface Type

BNC

Weight

283g

Overall dimension

100 mmx23mmx55 mm

Bandwidth

DC-100MHz

Current

DC/AC RMS 30A

Rise time

≤3.5ns

Range sensitivity

0.1V/A 1V/A

Typical DC Accuracy

士1%+5mA@1V/A 士1%+20mA@0.1V/A

Maximum operating voltage

600V CATII 300V CATIII

Zero adjustment mode

Automatic

Power supply modenction

12V/2A power supply

Jaw diameter

Φ5mm

Interface Type

BNC

Weight

255g

Overall dimension

Current clamp handle size:176mm x 39.5mm x 18mm// Control box size:91.5mm x 40mm x 26.5mm

Delay time

Probe host 14ns //BNC 5ns (line length 1 m)

Cable length

Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m

Bandwidth

DC-60MHz

Current

DC/AC RMS 30A

Rise time

≤5.84ns

Range sensitivity

0.1V/A 1V/A

Typical DC Accuracy

士1%+1mA@1V/A 士1%+10mA@0.1V/A

Maximum operating voltage

600V CATII 300V CATIII

Zero adjustment mode

Automatic

Power supply modenction

12V/2A power supply

Jaw diameter

Φ5mm

Interface Type

BNC

Weight

255g

Overall dimension

Current clamp handle size (length * width * height):176mm x 39.5mm x 18mm// Control box size (length * width * height):91.5mm x 40mm x 26.5mm

Delay time

Probe host 14ns //BNC 5ns (line length 1 m)

Cable length

Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m

Bandwidth

DC-30MHz

Current

DC/AC RMS 30A

Rise time

≤11.7ns

Range sensitivity

0.1V/A 1V/A

Typical DC Accuracy

士1%+5mA@1V/A 士1%+20mA@0.1V/A

Maximum operating voltage

600V CATII 300V CATIII

Zero adjustment mode

Automatic

Power supply modenction

12V/2A power supply

Jaw diameter

Φ5mm

Interface Type

BNC

Weight

255g

Overall dimension

Current clamp handle size (length * width * height):176mm x 39.5mm x 18mm// Control box size (length * width * height):91.5mm x 40mm x 26.5mm

Delay time

Probe host 14ns //BNC 5ns (line length 1 m)

Cable length

Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m

Bandwidth

DC-50MHz

Current

DC/AC RMS 30A

Rise time

≤7ns

Range sensitivity

0.1V/A 1V/A

Typical DC Accuracy

士1%+5mA@1V/A 士1%+20mA@0.1V/A

Maximum operating voltage

600V CATII 300V CATIII

Zero adjustment mode

Automatic

Power supply modenction

12V/2A power supply

Jaw diameter

Φ5mm

Interface Type

BNC

Weight

255g

Overall dimension

Current clamp handle size :176mm x 39.5mm x 18mm// Control box size :91.5mm x 40mm x 26.5mm

Delay time

Probe host 14ns //BNC 5ns (line length 1 m)

Cable length

Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m

Bandwidth

DC-50MHz

Current

DC/AC RMS 50A

Rise time

≤7ns

Range sensitivity

0.1V/A 1V/A

Typical DC Accuracy

士1%+1mA@1V/A 士1%+10mA@0.1V/A

Maximum operating voltage

600V CATII 300V CATIII

Zero adjustment mode

Automatic

Power supply modenction

12V/2A power supply

Jaw diameter

Φ5mm

Interface Type

BNC

Weight

255g

Overall dimension

Current clamp handle size (length * width * height):176mm x 39.5mm x 18mm// Control box size (length * width * height):91.5mm x 40mm x 26.5mm

Delay time

Probe host 14ns //BNC 5ns (line length 1 m)

Cable length

Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m

Bandwidth

DC-120MHz

Current

DC/AC RMS 30A

Rise time

≤2.92ns

Range sensitivity

0.1V/A 1V/A

Typical DC Accuracy

士1%+1mA@1V/A 士1%+10mA@0.1V/A

Maximum operating voltage

600V CATII 300V CATIII

Zero adjustment mode

Automatic

Power supply modenction

12V/2A power supply

Jaw diameter

Φ5mm

Interface Type

BNC

Weight

255g

Overall dimension

Current clamp handle size:176mm x 39.5mm x 18mm// Control box size:91.5mm x 40mm x 26.5mm

Delay time

Probe host 14ns //BNC 5ns (line length 1 m)

Cable length

Control box to BNC connector cable length: 1m// Cable length from control box to current clamp: 1m
